TrueRC Pagoda 3B LHCP Antenna 5.1GHz

The Pagoda-3B LHCP design by Maarten Baert. This thoughtfully designed circular polarized antenna utilizes a 3 tiered 1 oz copper PCBs to replace the typically fragile wire elements.
It will work great as either TX or RX antenna. This is the Stubby at 50mm length.

Specification:

• Center frequency: 5.1 GHz

• Bandwidth: 500 MHz

• Matching: S11 < -20 dB, VSWR < 1.22 (at center frequency)

• Axial ratio: < 1.3

• Radiation efficiency: 95%

• LHCP

• Weight 6 gm

Package contains:

• 1x Pagoda 3B LHCP Antenna 5.1GHz
