HOLYBRO - PM08D Power Module 14S 200A 15024

Features:

• Support 2S - 14S Battery

• 200A Cont. Current Rating

• Easy to Setup

• Aluminum Case for Heat dissipation

Specification:

• Input Voltage: 2S-14S

• PCB Cont. Current Rating: 200A

• PCB Burst Current Rating: 1000A (

• Max Current Sensing: 237.6A

• Output: DC 5.1-5.3V & 3A Max

• Power Monitor Chip: INA228

• 5V BEC Connector Type: Molex CLIK-Mate 2mm 6Pin

• Dimensions: 101x45x26mm

• Mounting hole: 79mm*38.1mm

• Weight: 151g

Package contains:

• 1x PM08D Power Module

• 1x 40x40mm Fan

• 2x Molex CLIK-Mate 2.0mm 6Pin Cable 15 cm

• 4x Sets of Screws, Washers, and Nuts
